SPINETRAC
SPINETRAC® is a motorised spinal decompression therapy system that supports cervical, lumbar, hip, knee and carpal/wrist traction and decompression from a single multipurpose table. With supine, prone and side-lying (antalgic) treatment positions, Saunders cervical system, adjustable table height (21”–43” / 54–110 cm), manually adjustable pelvic tilt (0°–24°), repositionable headpiece, adjustable arm rests and patient stabilisation via axilla posts, it is designed for physiotherapy clinics, rehabilitation centres and pain management facilities that require multi-position spinal decompression capability.
Supine, Prone & Side-Lying
Saunders Cervical System
21”–43” Adjustable Height
0°–24° Pelvic Tilt
Multipurpose Treatment Table
Adjustable Head & Arm Rests
Multi-Region Decompression & Treatment Flexibility
SPINETRAC® provides cervical, lumbar, hip, knee and carpal decompression with supine/prone/side-lying positioning, Saunders cervical system and a multipurpose treatment table with adjustable height, pelvic tilt and patient stabilisation.
5 Treatment Regions — Back, Neck, Hip, Knee, Carpal
A single system handles spinal decompression/traction across five body regions: back (lumbar), neck (cervical via Saunders system), hip, knee and carpal/wrist. This eliminates the need for separate decompression devices per region, consolidating multi-region traction capability into one treatment station.
Supine, Prone & Side-Lying Positioning
Supports three treatment positions — supine (face up), prone (face down) and side-lying (antalgic positioning). Side-lying decompression accommodates patients who cannot tolerate supine or prone positions, expanding the treatable patient population compared to supine-only or prone-only systems.
Saunders Cervical System
Integrated Saunders cervical traction system for cervical spine decompression. The repositionable headpiece accommodates different patient sizes and cervical treatment angles.
Adjustable Table Height — 21” to 43”
Table height adjusts from 21 inches (54 cm) to 43 inches (110 cm), accommodating different practitioner heights, wheelchair transfers and treatment techniques. This range supports both low-position manipulation and standard-height decompression therapy.
0°–24° Pelvic Tilt & Patient Stabilisation
Pelvic tilt section is manually adjustable from 0° to 24° for lumbar positioning. Patient stabilisation is provided via axilla posts. Adjustable arm rests support patient comfort during extended decompression sessions.
Multipurpose Treatment & Manipulation Table
Functions as both a spinal decompression system and a general-purpose treatment/manipulation table. The dual-purpose design maximises the clinical utility of the table footprint — decompression therapy and manual treatment from the same station. Manufactured by HMS Medical Systems.
Engineered for Performance
Key features of SPINETRAC from multi-modality output and channel independence to display, safety and build quality.
- Saunders cervical system
- Supine treatment
- Prone treatment
- Side-lying decompression (Antalgic positioning)
- Carpal / Wrist device
- Hip / Angle device
- Increase treatment options : Back, Neck, Hip, Knee, Carpal traction / Decompression
- Multipurpose treatment & Manipulation table
- Increased result on disc patients
- Patient stabilization ( Provides axilla posts)
- Spinal traction / Decompression is highly effective and well researched
- Adjustable table height from 21” – 43” (54cm – 110cm)
- Pelvic tilt section 0o to 24o manually adjustable
- Repositionable headpiece
- Adjustable arm rests
- Model : Spinetrac – Decompression Therapy System
- Operation Mode : Electrical
- Usage : Clinical, Hospital, Personal
- Head Pillow – Elevates the head during treatment for added comfort.
- Clinical Cervical Traction – This clinical device is specifically designed to assist with cervical traction and comes in a one-size-fits-most design.
- Knee Bloster – Provides ideal body positioning, enhancing versatility across treatment applications.
- Axial Posts – Removable axilla posts for added stabilization on the table, minimizing slippage during supine traction.
- Round Bolster – Rounded positioning aid, Size : 13 × 62 cm.
- Wedge – Flat-surfaced positioning tool, Comes in two size: 55 x 55 x 10 cm
- QuikWrap Belt Set – Universally compatible for pelvic or lumbar traction applications, Supports up to 130 kg.
- Mains Power – 240V – 50Hz
- Current – Max 1A with 240V
- Total Dimensions – Table + Traction Arm : 252 cm
- Adjustments – Head angle inclination : -20° to +40°
Arm rest angle inclination : -20° to +40°
Pelvic angle inclination : 0° to +20°
Leg angle inclination : 0° to +45°
Leg section displacement : 13 cm
Maximum Table Height : 108 cm
Minimum Table Height : 59 cm
- Dynamic lifting capacity – < 201 kg
- Maximum work load – < 276 kg
- Electrical safety class – Class I, Type-B
- Table weight – 165 kg
- Average shipping weight – 250 kg
- Average shipment dimension – 236-244 X 84-91 X 64-79 cm
